Easy-Load Pump Head for High-Performance Tubing, PPS, SS Rotor
SKU
CP/P-07516-12
Brand
COLE-PARMER
In stock
Save time with fast tubing changes and reduced maintenance
- New design and automatic tubing retention allow for multiple tubing sizes—change tubing without removing head from drive
- Select either stainless steel (SS) or cold-rolled steel (CRS) rotor—choose CRS for economy or SS for greater durability and chemical resistance
- Pump heads are stackable for multichannel applications
- Compact design for efficient use of space
INCLUDES
single-channel mounting hardware.
MORE ABOUT THIS ITEM
This Easy-Load pump head accepts high-performance precision tubing— choose these pump heads for better pressure generation, suction lift, viscous fluid transfer, and longer tubing life. Select a pump head for one of the following high-performance tubing sizes: L/S 15, L/S 24.
Specifications & Description
- Pump Series: L/S
- Number of Channels: 1
- Max Flow Rate (mL/min): 1700
- Min Flow Rate (mL/min): 0.034
- Max Flow Rate Per Channel (mL/min): 1700
- Min Flow Rate Per Channel (mL/min): 0.034
- Housing Material: Polyphenylene Sulfide (PPS)
- Tubing Retention: Manual
- Occlusion: Fixed
- Optimum RPM Range (rpm): 0.02 to 600
- Rollers: Three; stainless steel
- Rotor Material: Stainless Steel
- Suction Lift (ft): 26.8
- Suction Lift (m): 8.2
- Gear Ratio: 1:1
- Tubing sizes accepted: L/S 15, L/S 24
- Volume Per Revolution With L/S 15 Tubing (mL): 1.7
- Volume Per Revolution With L/S 24 Tubing (mL): 2.8
- Length (in): 2.5
- Width (in): 4.5
- Height (in): 4
- Length (mm): 64
- Width (mm): 114
- Height (mm): 102
- Open-Head Sensor: No
- Description: L/S Easy-Load Head for High-Performance Tubing, PPS, SS Rotor
| Brand | COLE-PARMER |
|---|
